Specifications
| Optical Design |
Apochromatic Refractor |
| Optical Diameter |
150mm |
| Focal Length |
1050mm |
| F/Ratio |
F/7 |
| Highest Practical Power |
300x |
| Faintest Steller Magnitude |
13 |
| Finder Scope |
8x50 Right Angled Erect Image |
| Focuser Diameter |
3" Linear Power Focuser |
| Diagnol |
2" 90 deg. Dielectric Diagonal with 1.25" adapter |
| Tube Weight |
14.52 kg |
| Tube Dimensions |
15.3cmx95cm |
| Shipping Weight |
30 kg |
| Shipping Dimensions |
130x56x56 cm3 |
Esprit 80ED, 100ED, 120ED and 150ED Super APO refractors have a doublet field flattener to get a flat field and minimize aberration and distortion. Their wide 48mm opener ensures a larger and clearer aperture and also extremely minimized halation. Connect the triplet and doublet field flattener with a high precision thin thread to keep the optical axis perpendicular to the image.
Main Features:
- Premium optical materials
- Short focal length and full frame corrected focal plane
- Excellent field flatness
- Precision linear power focuser is standard
- Metallic high-transmission lens coatings
- Light-baffled optical systems
- Telescope tube attachment hardware
- Full-frame Corrected Focal Plane
- Zero detectable Colour Fringing even on Bright Objects
- Knife-edge Baffled Optical System
